Ergotron LX Dual Side by Side Monitor Arm


$595.00 inc GST

Create a fully adjustable side-by-side monitor configuration that lifts both LCD screens up to where they’re easier to see while reclaiming valuable worksurface.


Reposition your screens with just a touch. Up. Down. Forward. Back. The LX provides an unparalleled range of motion.

Save time by using multiple applications at once – eliminate toggling back and forth between documents and programs.

Finished in a durable polished aluminum construction adding style to your work area!

Includes two arms, two extensions, pole, t-bracket, base, desk clamp and grommet mount.

Screen Requirements:

  • Screen must have Standard VESA Mount (100mm x 100mm & 75mm x 75mm)
  • Maximum Screen Size Supported: 27″
  • Larger displays cannot be positioned in a stacked orientation, but can be placed side by side
  • Maximum individual LCD weight capacity: 3.2-9.1kg (per monitor)
  • To support a laptop also order the Notebook Tray – Ergotron LX Notebook Tray
  • Maximum Load Capacity: 18.14kg


  • Arm extended reach: up to 640mm
  • Vertical height adjustment: 330mm
  • 360° Rotation, 360° Pan, 75° Tilt
  • Desk Clamp attaches to surface up to 66 mm thick
  • Grommet Mount attaches through surface holes 7 to 51 mm wide and up to 80 mm thick
  • Product Weight: 6.4kg


  • Designed for side-by-side or low-angle screen views
  • Dual purpose: Holds two screens up to 27″ in size
  • More workspace: Free up your desktop for office essentials
  • Larger displays (23″ to 27″) cannot be positioned in a stacked orientation (only be placed side by side)
  • Steel and aluminum construction offers durability and enhanced aesthetics
  • Quality design, built for years of use (by passing the 10,000-cycle motion test)
  • BIFMA level® 2 certified for a low environmental and social impact
  • Warranty: 10 years


Additional information

Weight 8 kg
Dimensions 49 × 45 × 16 cm
